CENTURION D6 SMART 600 KG Sliding Gate Motor UAE
Price 2,200 AEDIn Stock
The CENTURION D6 SMART Sliding Gate Motor is a powerful 24V DC automatic gate opener designed for sliding gates weighing up to 600 KG. Combining intelligent SMART technology, battery backup, fast gate movement and advanced security features, the D6 SMART is an excellent solution for residential, commercial and light-industrial sliding gate automation.
The CENTSYS D6 SMART features a battery-driven 24V system using two 12V batteries, allowing the gate to continue operating during mains power failures. Its intelligent charger provides battery management and onboard diagnostics for reliable everyday operation.
An onboard 433.92 MHz code-hopping multichannel receiver provides secure wireless gate control and can store up to 1,500 remote controls. Wireless smartphone configuration makes setup, diagnostics and system management easier for professional installers.
Key Features
- Original CENTURION Systems / CENTSYS gate motor
- Model D6 SMART
- Suitable for sliding gates up to 600 KG
- Maximum gate length up to 100 metres
- 24V DC motor
- Battery-driven operation
- 2 × 12V battery system
- Battery backup during mains power failure
- Maximum 150 operations per day
- 50% duty cycle with mains power available
- 30 kgf starting push force
- 17 kgf rated push force
- Wireless smartphone setup and configuration
- Intelligent battery charger with diagnostics
- Hall Effect position-control technology
- Electronic collision sensing
- Onboard 433.92 MHz code-hopping receiver
- Capacity for up to 1,500 remote controls
- Individually configurable inputs and outputs
- Improved theft-deterrent design
- Lockable manual key release
- IP55 protection rating
Technical Specifications
| Brand | CENTURION Systems / CENTSYS |
| Model | D6 SMART |
| Product Type | Automatic Sliding Gate Motor |
| Maximum Gate Weight | 600 KG |
| Maximum Gate Length | 100 m |
| Input Voltage | 110–240V AC, 50/60Hz |
| Mains Current Consumption | 430 mA |
| Motor Voltage | 24V DC |
| Motor Power Supply | Battery Driven – 2 × 12V |
| Motor Current at Rated Load | 13A |
| Starting Push Force | 30 kgf |
| Rated Push Force | 17 kgf |
| Maximum Operations Per Day | 150 |
| Duty Cycle | 50% with Mains Present |
| Collision Sensing | Electronic |
| Position Control | Hall Effect Technology |
| Receiver Type | Code-Hopping Multichannel Receiver |
| Receiver Frequency | 433.92 MHz |
| Remote Capacity | Up to 1,500 Remotes |
| Manual Override | Lockable Key Release |
| Protection Rating | IP55 |
| Operating Temperature | -15°C to +50°C |
CENTSYS D6 SMART 24V Sliding Gate Opener with Battery Backup
The CENTURION D6 SMART is engineered for automatic sliding gates weighing up to 600 KG. Its powerful 24V DC drive system provides reliable performance for residential, commercial and light-industrial gate installations.
600 KG Sliding Gate Capacity
The D6 SMART supports sliding gates weighing up to 600 KG and gate lengths of up to 100 metres. Correct motor selection should also consider gate condition, usage frequency, gate length and installation environment.
24V Battery Backup System
The CENTURION D6 SMART uses a 24V battery-driven system with two 12V batteries. This allows the automatic gate to continue operating during mains power failures.
An intelligent battery charger manages the battery system and provides onboard diagnostics for easier servicing and maintenance.
Up to 150 Operations Per Day
The D6 SMART is designed for up to 150 gate operations per day, making it suitable for properties requiring regular automatic vehicle access.
30 kgf Starting Push Force
The motor provides a 30 kgf starting push force and a 17 kgf rated push force, providing strong and controlled movement for compatible sliding gates.
Smartphone Setup & Configuration
CENTURION SMART technology enables wireless setup and configuration using a compatible smartphone. This allows professional installers to configure the gate operator and access diagnostic information without relying only on conventional control-board programming.
Hall Effect Position Control
The D6 SMART incorporates Hall Effect position-control technology for accurate monitoring of the gate position. The non-contact sensing system is designed for dependable operation in demanding gate automation environments.
Electronic Collision Sensing
Electronic collision sensing monitors resistance during gate movement. When correctly configured, the system can detect abnormal resistance and respond according to the programmed safety settings.
433.92 MHz Code-Hopping Receiver
The CENTURION D6 SMART includes an onboard 433.92 MHz code-hopping multichannel receiver with selective remote-control adding and deleting.
The receiver can store up to 1,500 remote controls, providing substantial user capacity for residential compounds, commercial properties and shared vehicle entrances.
Improved Theft Protection
The D6 SMART incorporates an improved theft-deterrent cage design. A vibration sensor can also be connected to compatible third-party equipment to provide notification when tampering with the gate motor is detected.
Manual Release
The CENTURION D6 SMART features a convenient lockable manual key release. The operator can be disengaged when manual gate movement is required.
IP55 Protection
The D6 SMART has an IP55 protection rating and is designed for outdoor automatic gate installations when installed according to the manufacturer's requirements.
Residential, Commercial & Light-Industrial Applications
- Villa sliding gates
- Residential compound entrances
- Apartment building gates
- Commercial property entrances
- Office parking gates
- Warehouse entrances
- Light-industrial sliding gates
- Vehicle access control gates
Professional Installation
Professional installation is recommended for the CENTURION D6 SMART. The sliding gate should move freely before automation, and the motor, gear rack, position-control system, safety devices and electronic settings should be correctly installed and configured.
CENTURION D6 SMART Sliding Gate Motor Supplier in UAE
AAM Automatic Doors & Gate Barriers supplies CENTURION D6 SMART 600 KG sliding gate motors in UAE for residential, commercial and light-industrial automatic sliding gates.
Supply, professional installation, replacement and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
