BENINCA BULL20M Sliding Gate Motor 2000 KG UAE
Price 3,500 AEDIn Stock
The BENINCA BULL20M Sliding Gate Motor is a powerful 230V electromechanical gate opener designed for industrial sliding gates weighing up to 2000 kg. Built for demanding vehicle access applications, the BULL20M combines a robust geared motor, integrated electronic control unit and encoder to provide reliable, precise and safe automatic gate operation.
The BENINCA BULL20M delivers a maximum thrust of 1667 N and an opening speed of approximately 10.5 metres per minute. Its 230V AC motor and 40% duty cycle make it suitable for industrial properties, warehouses, factories, commercial compounds and heavy sliding gate installations.
An integrated encoder provides accurate monitoring throughout the gate movement. The encoder supports obstacle detection and anti-crushing safety while helping maintain precise operation during opening, closing and slowdown phases.
The built-in CP.BULL-RI control unit features an LCD display, automatic parameter setup, electronic torque adjustment, adjustable slowdowns and electronic braking. An integrated 433.92 MHz radio receiver can store up to 64 transmitters and supports Advanced Rolling Code, Rolling Code and Fixed Code systems.
Key Features
- Genuine BENINCA industrial sliding gate motor
- Suitable for sliding gates up to 2000 kg
- Designed for industrial use
- 230V AC geared motor
- Maximum thrust of 1667 N
- Opening speed of 10.5 m/min
- 40% duty cycle
- Integrated CP.BULL-RI electronic control unit
- Integrated encoder
- Anti-crushing safety function
- Accurate gate movement monitoring
- Encoder-based obstacle detection
- Electronic motor torque adjustment
- Adjustable slowdown system
- Electronic braking for precise stopping
- Automatic operating parameter setup
- Integrated LCD display
- Built-in 433.92 MHz radio receiver
- Stores up to 64 remote transmitters
- Advanced Rolling Code support
- Rolling Code and Fixed Code support
- Pedestrian opening function
- Photocell inputs
- N.C. or 8K2 safety edge input
- IP44 protection rating
- M4 Z18 rack pinion
- Optional steel anti-vandal protective cover
- Foundation plate with anchor bolts included
Technical Specifications
| Brand | BENINCA |
| Model | BULL20M |
| Product Type | Industrial Sliding Gate Motor / Gate Opener |
| Use | Industrial |
| Maximum Gate Weight | 2000 kg |
| Power Supply | 230V AC, 50–60 Hz |
| Motor Supply | 230V AC |
| Maximum Absorbed Current | 2.9 A |
| Maximum Thrust | 1667 N |
| Opening Speed | 10.5 m/min |
| Duty Cycle | 40% |
| Control Unit | CP.BULL-RI Integrated |
| Encoder | Integrated |
| Radio Receiver | Integrated 433.92 MHz |
| Radio Memory | 64 Transmitters |
| Radio Encoding | Advanced Rolling Code / Rolling Code / Fixed Code |
| Rack Pinion | M4 Z18 |
| Protection Rating | IP44 |
| Operating Temperature | -20°C to +50°C |
| Lubrication | Grease |
| Motor Weight | 21.1 kg |
2000 KG Industrial Sliding Gate Automation
The BENINCA BULL20M 2000 kg sliding gate motor is engineered for large and heavy industrial sliding gates. Its powerful 230V AC motor produces up to 1667 N maximum thrust, providing reliable automation for gates weighing up to 2000 kg.
This makes the BULL20M suitable for factories, warehouses, industrial facilities, commercial compounds and other locations requiring dependable automatic vehicle access.
Encoder & Anti-Crushing Safety
The integrated encoder monitors gate movement and provides precise feedback to the electronic control system. This helps maintain accurate operation throughout the opening, closing and slowdown phases.
The encoder also supports obstacle detection and anti-crushing protection, allowing the control system to respond when abnormal resistance is detected during gate movement.
Integrated CP.BULL-RI Control Unit
The BENINCA BULL20M includes the CP.BULL-RI electronic control unit with an integrated LCD display for convenient programming, configuration and diagnostics.
The control board supports automatic, semi-automatic and deadman operating logic, open, close, pedestrian, step-by-step and stop commands, photocell inputs, safety-edge input, automatic parameter setup, electronic torque adjustment and adjustable slowdowns.
433.92 MHz Integrated Receiver
The integrated 433.92 MHz radio receiver can store up to 64 transmitters and supports BENINCA Advanced Rolling Code, Rolling Code and Fixed Code radio systems.
Compatible BENINCA remote controls can therefore be programmed directly into the BULL20M without requiring a separate external radio receiver.
Electronic Braking & Slowdown
The CP.BULL-RI control unit provides adjustable slowdown phases and an electronic braking system. Electronic braking helps provide precise stopping even when automating large and heavy sliding gates.
Applications
- Industrial sliding gates
- Heavy sliding gates up to 2000 kg
- Factory entrance gates
- Warehouse entrance gates
- Industrial compounds
- Commercial properties
- Large vehicle access gates
- Commercial parking entrances
- Automatic driveway gates
- Heavy-duty vehicle access control systems
