BENINCA BULL6M Sliding Gate Motor 600 KG UAE
Price 1,350 AEDIn Stock
The BENINCA BULL6M Sliding Gate Motor is a reliable 230V electromechanical gate automation system designed for residential sliding gates weighing up to 600 kg. It combines a powerful geared motor, integrated electronic control unit, encoder and magnetic limit switches in a compact solution for smooth and precise automatic gate operation.
Designed for residential gate automation, the BENINCA BULL6M delivers a maximum thrust of 650 N and an opening speed of approximately 10.5 metres per minute. The integrated encoder continuously assists the control system during gate movement, providing accurate operation and anti-crushing safety.
The built-in CP.BULL6 control unit includes an LCD display and an integrated 433.92 MHz radio receiver with Beninca Advanced Rolling Code (ARC). Up to 64 transmitters can be stored in the receiver, providing secure and convenient remote-control access.
With magnetic limit switches, adjustable opening and closing speeds, configurable slowdowns, photocell inputs and advanced diagnostic capabilities, the BULL6M SE.S is an excellent solution for villas, residential properties and other automatic sliding gate installations in the UAE.
Key Features
- Genuine Beninca sliding gate motor
- Suitable for sliding gates up to 600 kg
- 230V AC electromechanical geared motor
- Built-in CP.BULL6-SE electronic control unit
- Integrated encoder
- Anti-crushing safety function
- Magnetic limit switches
- Maximum thrust of 650 N
- Opening speed approximately 10.5 m/min
- 30% duty cycle
- Integrated 433.92 MHz radio receiver
- Beninca Advanced Rolling Code (ARC)
- Stores up to 64 remote transmitters
- Integrated LCD display
- Adjustable opening and closing speeds
- Adjustable slowdown settings
- Automatic parameter setup
- Pedestrian opening function
- Photocell and safety-edge inputs
- ESA+ energy-saving function
- Compatible with optional smart connectivity accessories
- Suitable for residential sliding gates
Technical Specifications
| Brand | BENINCA |
| Model | BULL6M |
| Product Type | Sliding Gate Motor / Gate Opener |
| Use | Residential |
| Maximum Gate Weight | 600 kg |
| Power Supply | 230V AC, 50–60 Hz |
| Motor Supply | 230V AC |
| Maximum Current | 1.3 A |
| Maximum Thrust | 650 N |
| Opening Speed | 10.5 m/min |
| Duty Cycle | 30% |
| Control Unit | CP.BULL6-SE Built-In |
| Radio Receiver | Integrated 433.92 MHz ARC Receiver |
| Remote Memory | Up to 64 Transmitters |
| Encoder | Integrated |
| Limit Switches | Magnetic |
| Rack Pinion | M4 Z18 |
| Operating Temperature | -20°C to +50°C |
| Lubrication | Grease |
| Motor Weight | 10.9 kg |
Integrated CP.BULL6-SE Control Unit
The Beninca BULL6M includes the CP.BULL6-SE electronic control unit directly inside the gate motor. The control board features an integrated LCD display that simplifies programming, configuration and system diagnostics.
Operating parameters can be automatically configured using the auto-set function. Separate electronic adjustments are available for opening and closing speeds, while adjustable slowdowns help provide smooth gate movement near the fully open and closed positions.
Encoder & Anti-Crushing Safety
The integrated encoder provides accurate monitoring during automatic gate movement. This improves positioning precision and supports the motor's anti-crushing safety system, allowing the automation to respond when an obstacle interferes with normal gate movement.
Magnetic Limit Switches
The BULL6M is equipped with magnetic limit switches for accurate detection of the gate's opening and closing positions. Magnetic limit technology provides reliable positioning without relying on conventional mechanical limit-switch activation.
433.92 MHz ARC Receiver
The built-in receiver operates at 433.92 MHz and supports Beninca Advanced Rolling Code (ARC) technology. The receiver can store up to 64 remote transmitters, providing secure remote operation for residential gate access.
Smart Configuration & Diagnostics
The BULL6M SE.S control system is prepared for connection to optional X.BE (KNX) and Q.BE (MQTT) accessories. It also supports configuration and diagnostics through the Beninca BeUP system when used with the compatible PRO.UP accessory.
Compatible smart configuration functions can include parameter adjustment, logic configuration, error-message reading, firmware updates, gate status checks, remote diagnostics and gate commands.
Applications
- Residential sliding gates
- Villa entrance gates
- Private house gates
- Residential compounds
- Sliding gates weighing up to 600 kg
- Automatic driveway gates
- Residential parking entrances
Beninca BULL6M Supplier in UAE
AAM Automatic Doors & Gate Barriers supplies Beninca BULL6M sliding gate motors in UAE, together with Beninca remote controls, photocells, flashing lights, control boards, gear racks and gate automation accessories.
Supply, professional installation and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
