RIB K1400 1400 KG Sliding Gate Motor UAE

The RIB K1400 Sliding Gate Motor is a heavy-duty automatic gate operator designed for sliding gates weighing up to 1400 KG. Engineered by RIB for demanding residential, commercial and industrial applications, the K1400 combines powerful electromechanical operation with advanced electronic movement control.

The RIB K1400 features gradual start, electronic force adjustment, slowdown during approach and electronic braking, providing smooth and controlled gate movement. These functions help reduce mechanical impact while improving the overall operation of large and heavy sliding gates.

For applications requiring increased operating speed, the RIB K1400 INV version uses inverter technology to provide gradual acceleration, high-speed movement and controlled deceleration near the end of the gate travel.

Key Features

• Original RIB K1400 sliding gate motor
• Suitable for sliding gates up to 1400 KG
• Heavy-duty electromechanical operator
• Irreversible drive system
• Gradual motor start
• Electronic force adjustment
• Automatic slowdown during approach
• Electronic braking
• Smooth and controlled gate movement
• Manual release with personalized key
• Photocell safety management
• Photocell auto-test with compatible L1-CRX configuration
• Removable remote-control code memory with L1-CRX
• Up to 1000 SUN / SUN-PRO transmitters with L1-CRX
• Optional APP / APP+ Bluetooth management
• Optional thermal probe support with compatible L1-CRX version
• K1400 INV high-speed version available
• Suitable for residential, commercial and industrial gates

Technical Specifications

RIB K1400 1400 KG Sliding Gate Opener

The RIB K1400 is designed for automatic sliding gates weighing up to 1400 KG. Its heavy-duty construction makes it suitable for larger gates where residential-class operators may not provide sufficient capacity.

The motor can be used for large villas, apartment buildings, commercial properties, warehouses, factories and other access-controlled entrances requiring dependable sliding gate automation.

Heavy-Duty 1400 KG Gate Motor

With a maximum gate capacity of 1400 KG, the RIB K1400 is positioned for demanding sliding gate installations.

Motor selection should consider not only gate weight but also gate length, wheel condition, track resistance, usage frequency and environmental conditions.

Gradual Start Function

The RIB K1400 provides a gradual starting function, allowing the sliding gate to begin movement progressively rather than applying maximum movement force immediately.

This helps provide smoother operation and reduces mechanical shock on the gate, gear rack, motor and transmission components.

Automatic Gate Slowdown

The RIB K series provides gate slowdown during approach, allowing the gate to reduce speed before reaching its final opening or closing position.

This controlled approach provides smoother gate movement and helps reduce mechanical impact at the end of travel.

Electronic Force Adjustment

The K1400 control system provides electronic motor force regulation, allowing the installer to configure the automation according to the characteristics and movement resistance of the sliding gate.

Correct force adjustment is important for reliable, smooth and safe automatic gate operation.

Electronic Brake

The RIB K1400 incorporates an electronic braking function to provide improved control of the gate during automatic movement.

Together with gradual starting and approach slowdown, electronic braking helps provide controlled movement throughout the opening and closing cycle.

Irreversible Gate Operator

The RIB K1400 is an irreversible sliding gate operator. Its mechanical transmission helps maintain the gate position when the motor is stopped.

The complete installation should include correctly positioned mechanical stops and a properly installed gear rack for dependable operation.

RIB K1400 INV High-Speed Version

For applications requiring faster gate movement, RIB offers the K1400 INV high-speed version.

The inverter-based control system provides gradual acceleration, high-speed travel and controlled slowdown as the gate approaches the end of the manoeuvre.

This version is particularly useful for long and heavy sliding gates where reducing vehicle waiting time is important.

Manual Release During Power Failure

The RIB K1400 includes a manual release system with personalized key, allowing the gate motor to be disengaged during a power failure, emergency or maintenance.

After releasing the operator, the sliding gate can be moved manually when the gate itself is correctly maintained and moves freely.

Up to 1000 Remote Controls

Compatible K1400 installations using the L1-CRX control panel can manage up to 1000 RIB SUN or SUN-PRO remote controls.

This large transmitter capacity makes the system suitable for apartment communities, commercial buildings, warehouses and other properties requiring access for many authorised users.

Removable Remote Control Memory

The L1-CRX control system provides removable remote-control code memory, helping simplify maintenance and replacement of compatible control equipment.

Stored transmitter information can therefore be managed more conveniently during professional maintenance or control-board servicing.

Photocell Safety Sensors

Compatible RIB photocell safety sensors can be integrated with the K1400 to detect vehicles, pedestrians and other obstacles across the automatic gate entrance.

With compatible L1-CRX configurations, photocell auto-testing is also supported as part of the gate safety system.

RIB FIT SLIM Photocell Compatibility

The RIB K1400 can be installed with compatible RIB FIT SLIM photocell sensors for infrared obstacle detection.

Photocells should be correctly positioned and aligned according to the gate movement area and required safety protection.

RIB SUN Remote Control Compatibility

The RIB K1400 can be operated using compatible RIB SUN and SUN-PRO remote controls when the appropriate radio receiver and control configuration are installed.

Remote controls can be programmed for authorised users according to the requirements of the property.

Optional Bluetooth Management

Compatible L1-CRX installations can be managed using optional RIB APP or APP+ Bluetooth cards.

These accessories provide additional configuration and management options for compatible professional gate automation installations.

Optional Thermal Probe

Compatible K1400 versions equipped with the L1-CRX panel can use the optional ACG4665 thermal probe to help keep the motor warm in extremely low-temperature environments.

This feature is primarily relevant to cold-climate installations and is generally not required for normal UAE operating conditions.

Access Control Integration

The RIB K1400 can be integrated with compatible external access control equipment through suitable gate-control inputs.

• GSM gate openers
• WiFi gate controllers
• RFID access control systems
• Keypad access control
• UHF long-range vehicle readers
• Loop detectors
• Intercom systems
• Video intercom systems
• Push buttons
• Key switches

Commercial & Industrial Applications

• Large villa sliding gates
• Apartment buildings
• Residential compounds
• Commercial properties
• Factories
• Warehouses
• Logistics facilities
• Industrial entrances
• Business parks
• Private parking facilities
• Access-controlled entrances

Professional RIB K1400 Installation

Professional installation is recommended for the RIB K1400. A heavy sliding gate must move freely and smoothly by hand before an automatic gate motor is installed.

The gate track, wheels, foundation, motor position, gear rack, mechanical stops, electrical wiring and safety devices should all be correctly installed and adjusted before commissioning.

RIB K1400 Sliding Gate Motor Supplier in UAE

AAM Automatic Doors & Gate Barriers supplies RIB K1400 1400 KG sliding gate motors in UAE for heavy residential, commercial and industrial automatic gate applications.

Supply, professional installation, programming, maintenance, repair and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
