CAME KRONO KR310D Swing Gate Motor UAE
Price 0 AEDIn Stock
The CAME KRONO KR310D Swing Gate Motor is a professional 230V automatic gate operator designed for residential and commercial swing gates. The KR310D is a right-hand irreversible gearmotor suitable for gate leaves up to 3 metres long and 400 kg.
The CAME 001KR310D features adjustable opening and closing limit-switch microswitches for accurate gate travel control. Its robust die-cast aluminium construction makes the KRONO series a reliable solution for automatic swing gate installations.
Powered by a 230V AC motor with 240W power, the KR310D delivers adjustable thrust from 400N to 3000N and completes a 90° gate movement in approximately 22 seconds.
With an IP54 protection rating and operating temperature from -20°C to +55°C, the CAME KRONO KR310D is suitable for professional automatic swing gate installations in residential villas, commercial properties and other vehicle entrances.
Key Features
- Original CAME swing gate motor
- CAME KRONO Series
- Model KR310D
- Product code 001KR310D
- Right-hand irreversible gearmotor
- 230V AC motor
- 240W motor power
- Suitable for gate leaves up to 3 metres
- Maximum 400 kg gate weight at 3 metres
- Opening and closing limit-switch microswitches
- 22-second maneuvering time at 90°
- Adjustable thrust from 400N to 3000N
- Maximum 16 cycles per hour
- IP54 protection rating
- Operating temperature -20°C to +55°C
- Integrated emergency manual release
- Robust die-cast aluminium construction
- Suitable for residential and commercial swing gates
Technical Specifications
| Brand | CAME |
| Series | KRONO |
| Model | KR310D |
| Product Code / SKU | 001KR310D |
| Motor Type | Right-Hand Irreversible Gearmotor |
| Maximum Leaf Length | 3 m |
| Maximum Leaf Weight | 400 kg at 3 m |
| Power Supply | 230V AC, 50/60Hz |
| Motor Power Supply | 230V AC |
| Power | 240W |
| Current Draw | 1.1A |
| Thrust | 400–3000N |
| Maneuvering Time at 90° | 22 Seconds |
| Cycles Per Hour | 16 Max. |
| Limit Switch | Opening & Closing Microswitches |
| Protection Rating | IP54 |
| Operating Temperature | -20°C to +55°C |
| Motor Thermal Protection | 150°C |
CAME 001KR310D 230V Swing Gate Opener for Gates up to 3 Metres
The CAME KRONO KR310D is designed for automatic swing gate leaves up to 3 metres long. At the maximum 3 metre leaf length, CAME specifies a maximum gate leaf weight of 400 kg.
The operator can also accommodate heavier gate leaves when the leaf length is reduced, subject to the installation geometry and CAME operating limits.
Gate Weight & Length Capacity
| Gate Leaf Length | Maximum Leaf Weight |
| 3.0 m | 400 kg |
| 2.5 m | 600 kg |
| 2.0 m | 800 kg |
Right-Hand KRONO Swing Gate Motor
The KR310D is the right-hand version of the CAME KRONO 3 metre swing gate operator. For installations requiring the corresponding left-hand operator, CAME provides the KR310S.
For a double-leaf swing gate installation, the correct right-hand and left-hand operators should be selected according to the gate layout and installation requirements.
Opening & Closing Limit Switches
The CAME KR310D incorporates opening and closing limit-switch microswitches. These allow the installer to set and control the required gate travel positions.
Correct adjustment of the limit switches helps provide accurate stopping positions during automatic opening and closing.
230V Motor with 240W Power
The KR310D operates from a 230V AC power supply and uses a 240W motor. It delivers adjustable thrust ranging from 400N to 3000N for reliable swing gate movement.
22-Second Opening Time
The CAME KRONO KR310D has a maneuvering time of approximately 22 seconds at 90°, providing controlled automatic opening and closing for residential and commercial swing gates.
Up to 16 Cycles Per Hour
The KR310D is rated for a maximum of 16 operating cycles per hour, making it suitable for residential and suitable commercial automatic gate applications.
Robust Aluminium Construction
The CAME KRONO range features a strong die-cast aluminium structure designed to provide durability and dependable performance for automatic swing gate installations.
IP54 Protection
The CAME KR310D has an IP54 protection rating and an operating temperature range from -20°C to +55°C.
Correct installation, electrical protection and regular maintenance are important for reliable outdoor gate automation operation.
Manual Emergency Release
The CAME KRONO series incorporates an emergency release system that allows the operator to be manually released when manual gate movement is required, such as during a power failure or maintenance.
CAME ZA3P Control Panel Compatible
The KR310D can be used with the compatible CAME ZA3P control panel for two-leaf swing gate automation. The ZA3P provides limit-switch control and slow-down speed adjustment for compatible CAME swing gate operators.
Applications
- Automatic swing gates
- Residential villa gates
- Single-leaf swing gates
- Double-leaf swing gates
- Residential compounds
- Apartment building entrances
- Commercial properties
- Office entrance gates
- Automatic driveway gates
- Swing gate automation replacement
CAME KRONO KR310D Swing Gate Motor Supplier in UAE
AAM Automatic Doors & Gate Barriers supplies CAME KRONO KR310D swing gate motors in UAE together with compatible CAME control boards, remote controls, photocell sensors, flashing lights, electric locks and automatic gate accessories.
Supply, installation, programming, repair and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
