CAME ATI A5000 Swing Gate Motor UAE
Price 0 AEDIn Stock
The CAME ATI A5000 Swing Gate Motor is a powerful 230V automatic gate operator designed for large residential and commercial swing gates. The A5000 is an irreversible electromechanical gearmotor suitable for gate leaves up to 5 metres long and 400 kg.
The CAME 001A5000 features an opening limit-switch microswitch for accurate control of the gate opening position. Its long linear actuator design makes it particularly suitable for large swing gate leaves requiring reliable automatic opening and closing.
Powered by a 230V AC motor with 260W power, the ATI A5000 delivers adjustable thrust from 400N to 4000N and provides a maneuvering time of approximately 30 to 40 seconds at 90°.
With an IP44 protection rating and operating temperature from -20°C to +55°C, the CAME ATI A5000 provides dependable automation for villas, residential compounds, commercial properties and large entrance gates.
Key Features
- Original CAME swing gate operator
- CAME ATI Series
- Model A5000
- Product code 001A5000
- Irreversible electromechanical gearmotor
- 230V AC motor
- 260W motor power
- Maximum gate leaf length up to 5 metres
- Maximum 400 kg leaf weight at 5 metres
- Maximum 500 kg leaf weight at 4 metres
- Maximum 600 kg leaf weight at 3 metres
- Opening limit-switch microswitch
- 400–4000N thrust
- 30–40 second maneuvering time at 90°
- Up to 15 cycles per hour
- IP44 protection rating
- Operating temperature -20°C to +55°C
- Manual release for emergency operation
- Suitable for single and double swing gates
Technical Specifications
| Brand | CAME |
| Series | ATI |
| Model | A5000 |
| Product Code / SKU | 001A5000 |
| Product Type | Swing Gate Motor |
| Gearmotor Type | Irreversible |
| Maximum Leaf Length | 5 m |
| Maximum Leaf Weight | 400 kg at 5 m |
| Motor Power Supply | 230V AC, 50/60Hz |
| Absorption | 1.2A |
| Motor Power | 260W |
| Thrust | 400–4000N |
| Maneuvering Time at 90° | 30–40 Seconds |
| Cycles Per Hour | 15 |
| Limit Switch | Opening Limit-Switch Microswitch |
| Protection Rating | IP44 |
| Operating Temperature | -20°C to +55°C |
| Motor Thermal Protection | 150°C |
CAME 001A5000 230V Swing Gate Opener for Gates up to 5 Metres
The CAME ATI A5000 is designed for large automatic swing gate leaves measuring up to 5 metres long. At the maximum 5 metre leaf length, CAME specifies a maximum gate leaf weight of 400 kg.
For shorter gate leaves, the A5000 can accommodate higher gate weights according to CAME's specified operating limits.
Gate Weight & Leaf Length Capacity
| Gate Leaf Length | Maximum Leaf Weight |
| 5.0 m | 400 kg |
| 4.0 m | 500 kg |
| 3.0 m | 600 kg |
230V Motor with 260W Power
The CAME ATI A5000 operates from a 230V AC power supply and uses a 260W motor. The operator delivers adjustable thrust ranging from 400N to 4000N for dependable movement of large swing gate leaves.
Opening Limit-Switch Microswitch
The CAME 001A5000 incorporates an opening limit-switch microswitch for control of the gate's opening travel position.
Correct adjustment of the limit switch helps provide accurate and reliable automatic gate operation.
30–40 Second Gate Movement
The CAME ATI A5000 provides a maneuvering time of approximately 30 to 40 seconds at 90°. The controlled movement is suitable for large swing gate leaves where smooth and dependable operation is important.
Up to 15 Cycles Per Hour
The A5000 is rated for up to 15 cycles per hour, making it suitable for residential and appropriate commercial swing gate applications.
Designed for Large 5 Metre Swing Gates
One of the main advantages of the CAME ATI A5000 is its ability to automate gate leaves up to 5 metres long. This makes it suitable for wide villa entrances, residential compounds and commercial properties where shorter swing gate actuators may not be suitable.
Single & Double Swing Gate Automation
The CAME ATI A5000 can be installed on a single swing gate leaf or used as part of a double-leaf automatic gate system with two compatible operators and the appropriate CAME control panel.
Manual Release During Power Failure
The CAME ATI A5000 includes a manual release system that allows the operator to be disengaged when manual gate movement is required, such as during a power failure or maintenance.
IP44 Protection
The CAME ATI A5000 has an IP44 protection rating and an operating temperature range from -20°C to +55°C.
Applications
- Large automatic swing gates
- Villa entrance gates
- 5 metre swing gate leaves
- Single-leaf swing gates
- Double-leaf swing gates
- Residential compounds
- Commercial properties
- Apartment building entrances
- Automatic driveway gates
- Swing gate motor replacement
CAME ATI A5000 Swing Gate Motor Supplier in UAE
AAM Automatic Doors & Gate Barriers supplies CAME ATI A5000 swing gate motors in UAE together with compatible CAME control boards, remote controls, photocell sensors, flashing lights, electric locks and automatic gate accessories.
Supply, installation, programming, repair and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
