CAME ATI A3000 Swing Gate Motor UAE
Price 0 AEDIn Stock
The CAME ATI A3000 Swing Gate Motor is a reliable 230V automatic gate operator designed for residential and commercial swing gates. The A3000 is an irreversible electromechanical gearmotor suitable for gate leaves up to 3 metres long and 400 kg.
The CAME 001A3000 features an opening limit-switch microswitch for accurate control of the gate opening position. Its robust construction and powerful linear drive make it suitable for single-leaf and double-leaf automatic swing gate installations.
Powered by a 230V AC motor with 260W power, the CAME ATI A3000 delivers adjustable thrust from 400N to 4000N and provides a maneuvering time of approximately 19 to 25 seconds at 90°.
With an IP44 protection rating and operating temperature from -20°C to +55°C, the CAME ATI A3000 provides dependable automatic gate operation for villas, residential properties and commercial entrances.
Key Features
- Original CAME swing gate operator
- CAME ATI Series
- Model A3000
- Product code 001A3000
- Irreversible electromechanical gearmotor
- 230V AC motor
- 260W motor power
- Maximum gate leaf length up to 3 metres
- Maximum 400 kg leaf weight at 3 metres
- Up to 600 kg at 2.5 metres
- Up to 800 kg at 2 metres
- Opening limit-switch microswitch
- 400–4000N thrust
- 19–25 second maneuvering time at 90°
- Up to 24 cycles per hour
- IP44 protection rating
- Operating temperature -20°C to +55°C
- Manual release for emergency operation
- Suitable for single and double swing gates
Technical Specifications
| Brand | CAME |
| Series | ATI |
| Model | A3000 |
| Product Code / SKU | 001A3000 |
| Product Type | Swing Gate Motor |
| Gearmotor Type | Irreversible |
| Maximum Leaf Length | 3 m |
| Maximum Leaf Weight | 400 kg at 3 m |
| Motor Power Supply | 230V AC, 50/60Hz |
| Absorption | 1.2A |
| Motor Power | 260W |
| Thrust | 400–4000N |
| Maneuvering Time at 90° | 19–25 Seconds |
| Cycles Per Hour | 24 |
| Limit Switch | Opening Limit-Switch Microswitch |
| Protection Rating | IP44 |
| Operating Temperature | -20°C to +55°C |
| Motor Thermal Protection | 150°C |
CAME 001A3000 230V Swing Gate Opener for Gates up to 3 Metres
The CAME ATI A3000 is designed for automatic swing gate leaves up to 3 metres long. At the maximum 3 metre leaf length, the operator supports a maximum gate leaf weight of 400 kg.
For shorter gate leaves, the operator can accommodate higher gate weights according to CAME's specified operating limits.
Gate Weight & Leaf Length Capacity
| Gate Leaf Length | Maximum Leaf Weight |
| 3.0 m | 400 kg |
| 2.5 m | 600 kg |
| 2.0 m | 800 kg |
230V Motor with 260W Power
The CAME ATI A3000 operates from a 230V AC power supply and uses a 260W motor. It delivers thrust ranging from 400N to 4000N for dependable swing gate movement.
Opening Limit-Switch Microswitch
The CAME 001A3000 incorporates an opening limit-switch microswitch that allows the installer to control the gate's opening travel position.
Correct adjustment of the limit switch helps provide accurate and reliable automatic gate operation.
19–25 Second Gate Movement
The CAME ATI A3000 has a maneuvering time of approximately 19 to 25 seconds at 90°, providing controlled opening and closing movement for residential and commercial swing gates.
Up to 24 Cycles Per Hour
The operator is rated for up to 24 cycles per hour, making it suitable for residential properties and suitable commercial automatic gate applications.
Single & Double Swing Gate Automation
The CAME ATI A3000 can be used for single-leaf swing gates or as part of a double-leaf automatic gate system using two operators and a compatible CAME control panel.
Compatible CAME ZA3P Control Panel
For double-leaf installations, the ATI A3000 can be combined with the compatible CAME ZA3P multifunction control panel. The control panel manages both swing gate motors together with compatible command and safety accessories.
Manual Release During Power Failure
The CAME ATI A3000 incorporates a manual release system that allows the gate operator to be disengaged when manual gate operation is required, such as during a power failure or maintenance.
IP44 Protection
The CAME ATI A3000 has an IP44 protection rating and an operating temperature range from -20°C to +55°C.
Applications
- Automatic swing gates
- Residential villa gates
- Single-leaf swing gates
- Double-leaf swing gates
- Residential compounds
- Apartment building entrances
- Commercial entrance gates
- Office entrances
- Automatic driveway gates
- Swing gate motor replacement
CAME ATI A3000 Swing Gate Motor Supplier in UAE
AAM Automatic Doors & Gate Barriers supplies CAME ATI A3000 swing gate motors in UAE together with compatible CAME control boards, remote controls, photocell sensors, flashing lights, electric locks and automatic gate accessories.
Supply, installation, programming, repair and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
