Rolling Shutter Side Motor 1500 KG UAE

The Rolling Shutter Side Motor 1500 KG is a heavy-duty automatic shutter motor designed for large commercial and industrial rolling shutter doors. With a maximum lifting capacity of up to 1500 KG and rated output torque of 1617Nm, it provides powerful and reliable operation for demanding roller shutter applications.

Operating on 220V AC / 50Hz, the motor delivers 1250W input power with a rated current of 3.8A and output speed of 5.2 rpm. It supports compatible rolling shutter installations with a maximum lifting height of up to 8 metres.

The heavy-duty side-mounted design is suitable for factories, warehouses, industrial buildings, workshops, large commercial entrances, storage facilities and other applications requiring reliable automation of heavy rolling shutter doors.

Key Features

• Heavy-duty rolling shutter side motor
• Maximum lifting capacity up to 1500 KG
• 1617Nm rated output torque
• 220V AC / 50Hz operation
• 1250W input power
• 3.8A rated current
• 5.2 rpm rated output speed
• Maximum lifting height up to 8 metres
• 15-minute continuous working time
• Operating temperature from -20°C to +50°C
• Overheat protection
• Overload protection
• Manual operation during power failure
• Precise limit switch adjustment
• Low-noise operation
• Anti-fall protection
• Low-maintenance design
• Suitable for commercial and industrial shutters

Technical Specifications

1500 KG Rolling Shutter Side Motor

The motor provides a maximum lifting capacity of up to 1500 KG, making it suitable for compatible heavy commercial and industrial rolling shutter doors.

The actual shutter curtain weight, dimensions, shaft arrangement and complete mechanical configuration should always be checked before selecting the motor.

1617Nm Heavy-Duty Shutter Motor

With a rated output torque of 1617Nm, the 1500 KG side motor provides powerful mechanical performance for demanding automatic rolling shutter applications.

Its high torque makes it suitable for large roller shutters where lower-capacity shutter motors may not provide sufficient lifting force.

220V AC Rolling Shutter Motor

The motor operates from a 220V AC / 50Hz electrical supply with a rated current of approximately 3.8A.

Professional electrical installation is recommended to ensure correct motor wiring, electrical protection and control connections.

1250W Industrial Rolling Shutter Motor

The 1500 KG motor has a rated input power of 1250W, providing strong performance for compatible heavy roller shutter applications.

The electrical supply, cables, circuit protection and shutter controller should be correctly selected according to the motor specifications.

5.2 RPM Output Speed

The motor operates at a rated output speed of approximately 5.2 rpm.

Actual shutter opening and closing speed will also depend on the shaft diameter and complete mechanical configuration.

Up to 8 Metres Lifting Height

The 1500 KG side motor supports a maximum lifting height of up to approximately 8 metres.

The complete shutter dimensions and weight should be checked before installation to confirm that the motor is suitable for the application.

15-Minute Continuous Working Time

The motor has a specified continuous working time of up to 15 minutes, making it suitable for compatible heavy-duty rolling shutter applications.

The motor should always be operated according to its specified duty requirements to help maintain reliable performance and service life.

Overheat & Overload Protection

The motor incorporates overheat and overload protection to help protect the motor during abnormal operating conditions.

Correct motor sizing remains essential because excessive shutter load can affect performance and motor service life.

Manual Operation During Power Failure

The rolling shutter side motor provides a manual operating method for use when normal electrical power is unavailable.

This allows compatible rolling shutters to be manually operated during a power failure.

Precise Limit Switch Control

The motor incorporates an adjustable limit switch system for setting the fully open and fully closed positions of the rolling shutter.

Correct limit adjustment helps ensure that the motor automatically stops at the required upper and lower positions.

Anti-Fall Protection

The motor system incorporates an anti-fall protection device for compatible rolling shutter installations.

All mechanical and electrical safety components should be correctly installed and maintained as part of the complete shutter system.

Industrial Rolling Shutter Motor

The 1500 KG motor is designed for compatible industrial rolling shutter doors requiring high lifting capacity and strong output torque.

Typical applications include factories, industrial buildings, warehouses, workshops and heavy commercial entrances.

Rolling Shutter Motor for Warehouses

Large warehouse entrances frequently require powerful side-mounted motors because of the size and weight of the rolling shutter curtain.

With up to 1500 KG lifting capacity and 1617Nm rated torque, this motor is suitable for compatible heavy warehouse shutter applications.

Rolling Shutter Motor for Factories

The motor can be installed on compatible factory rolling shutters and industrial entrances requiring reliable automatic opening and closing.

The actual shutter weight, dimensions and operating frequency should be considered when selecting the correct motor.

Rolling Shutter Motor for Workshops

The 1500 KG side motor is suitable for compatible workshop and industrial roller shutter doors where high lifting capacity is required.

Rolling Shutter Motor for Commercial Buildings

Large commercial properties can use the 1500 KG motor for compatible heavy roller shutters installed at shopping centres, showrooms, storage facilities and commercial entrances.

Rolling Shutter Push Button Control

The motor can be connected to a compatible OPEN / STOP / CLOSE or UP / STOP / DOWN control station.

This provides convenient local operation of the automatic rolling shutter.

Rolling Shutter Remote Control

A compatible rolling shutter receiver or motor controller can be installed to provide wireless remote-control operation.

Users can then conveniently open, stop and close the rolling shutter using compatible remote transmitters.

Rolling Shutter Motor Replacement

The 1500 KG side motor can be used as a replacement for a compatible existing heavy-duty rolling shutter motor.

Before replacement, check the existing motor's lifting capacity, voltage, power, torque, mounting arrangement, shaft configuration and electrical connections.

1500 KG Rolling Shutter Motor Applications

• Industrial rolling shutter doors
• Warehouse roller shutters
• Factory entrances
• Heavy commercial shutters
• Workshop roller shutters
• Shopping centre shutters
• Large showroom shutters
• Storage facility shutters
• Industrial building entrances
• Loading area shutters
• Commercial roller doors
• Replacement rolling shutter motors

Professional Rolling Shutter Motor Installation

Professional installation is recommended to ensure correct motor sizing, mounting, shaft alignment, electrical wiring, limit adjustment and safety setup.

Before selecting the 1500 KG motor, the actual rolling shutter weight and mechanical dimensions should be checked to ensure sufficient lifting capacity and reliable operation.

Rolling Shutter Side Motor 1500 KG Supplier in UAE

AAM Automatic Doors & Gate Barriers supplies 1500 KG rolling shutter side motors in UAE for heavy commercial and industrial roller shutter applications.

Supply, installation and replacement services are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
