Rolling Shutter Tubular Motor 92mm 230Nm UAE
Price 999 AEDIn Stock
The Rolling Shutter Tubular Motor 92mm 230Nm is a powerful heavy-duty tubular motor designed for automatic rolling shutters and compatible roller shutter systems. With a large 92mm motor diameter and rated torque of 230Nm, it provides strong and reliable performance for larger commercial and industrial rolling shutter applications.
The motor operates on 230V AC / 50Hz and delivers 870W rated power with a rated current of 3.80A and rotational speed of 12rpm. It features IP44 protection, Class H insulation and an S2 4-minute operating duty.
Its tubular construction allows the motor to be installed inside a compatible roller tube, providing a compact automatic shutter solution while delivering the high torque required for demanding roller shutter applications.
Key Features
- Heavy-duty 92mm tubular motor
- 230Nm rated torque
- 230V AC operation
- 50Hz rated frequency
- 870W rated power input
- 3.80A rated current
- 12rpm rated speed
- S2 4-minute running time
- IP44 protection rating
- Class H insulation
- High-torque tubular motor design
- Internal roller tube installation
- Suitable for heavy rolling shutters
- Commercial and industrial applications
- Suitable for new and replacement installations
Technical Specifications
| Product Type | Rolling Shutter Tubular Motor |
| Motor Diameter | 92mm |
| Rated Torque | 230Nm |
| Rated Voltage | 230V AC |
| Rated Frequency | 50Hz |
| Rated Power Input | 870W |
| Rated Current | 3.80A |
| Rated Speed | 12rpm |
| Running Time | S2 4 Minutes |
| Protection Rating | IP44 |
| Insulation Class | Class H |
| Application | Heavy-Duty Automatic Rolling Shutters |
92mm Rolling Shutter Tubular Motor
The motor features a large 92mm tubular design for installation inside a compatible rolling shutter roller tube.
The larger motor body provides the capacity required for higher-torque applications compared with smaller 35mm, 45mm and 59mm tubular motors.
230Nm High-Torque Tubular Motor
With a rated torque of 230Nm, this tubular motor provides powerful rotational force for compatible heavy rolling shutter systems.
Motor selection should always be based on the actual shutter weight, width, height, roller tube diameter and complete mechanical configuration.
230V AC Rolling Shutter Motor
The tubular motor operates from a 230V AC / 50Hz electrical supply.
Professional electrical installation is recommended to ensure correct directional wiring, electrical protection and control connections.
870W Heavy-Duty Tubular Motor
The 92mm 230Nm motor has a rated power input of 870W and rated current of approximately 3.80A.
The electrical supply, cable size, controller and protective equipment should be correctly selected according to the motor specifications.
12rpm Rolling Shutter Motor
The motor provides a rated rotational speed of 12rpm for smooth and controlled opening and closing of compatible rolling shutters.
Actual shutter movement speed will also depend on the roller tube diameter and complete mechanical arrangement.
S2 4-Minute Duty Rating
The motor has an S2 4-minute duty rating, meaning it is designed for short-duration shutter operation rather than continuous running.
If repeated operation activates thermal protection, the motor should be allowed sufficient cooling time before further operation.
IP44 Tubular Motor
The 92mm tubular motor has an IP44 protection rating. The complete installation should still provide suitable protection for the motor, wiring and electrical connections.
Class H Motor Insulation
The motor uses Class H insulation for its winding insulation system.
Correct installation and operation within the specified duty cycle are important for reliable long-term motor performance.
Motor Installed Inside Roller Tube
Unlike an external rolling shutter side motor, the tubular motor is installed inside a compatible roller tube.
This provides a compact and professional shutter automation solution with the motor largely concealed inside the roller assembly.
Heavy-Duty Tubular Motor for Rolling Shutters
The combination of 92mm motor diameter, 230Nm torque and 870W power makes this model suitable for compatible heavy rolling shutter applications requiring a powerful internal motor.
The actual shutter load and roller tube dimensions should always be checked before installation.
Commercial Rolling Shutter Motor
The 92mm 230Nm tubular motor is suitable for compatible commercial rolling shutters requiring high torque and an internal motor installation.
Applications can include shops, showrooms, commercial buildings, workshops and storage facilities.
Industrial Rolling Shutter Tubular Motor
The high 230Nm torque rating makes this motor suitable for compatible industrial shutter applications where a heavy-duty tubular motor is required.
The complete shutter weight, operating frequency and mechanical configuration should be evaluated before selecting the motor.
Tubular Motor for Shop Rolling Shutters
The motor can automate compatible shop rolling shutter doors while remaining installed inside the roller tube.
The shutter weight and roller tube dimensions should be checked before installation to confirm motor and adapter compatibility.
Tubular Motor for Garage Rolling Shutters
The 230Nm motor can also be used for compatible garage rolling shutter doors requiring a powerful internal tubular motor.
The complete garage shutter load should be calculated before selecting the motor.
Tubular Motor for Warehouse Shutters
The 92mm 230Nm motor can be used for compatible warehouse roller shutter applications where the required torque and roller tube dimensions match the motor specifications.
For extremely large or heavy industrial shutters, a correctly sized side-mounted shutter motor may be more suitable.
Rolling Shutter Push Button Control
The motor can be operated using a compatible UP / STOP / DOWN or OPEN / STOP / CLOSE shutter control system.
This provides convenient local operation for opening, stopping and closing the automatic rolling shutter.
Rolling Shutter Remote Control
A compatible rolling shutter receiver or motor controller can be installed to provide wireless remote-control operation.
Users can then conveniently open, stop and close the shutter using compatible remote transmitters.
Smart Rolling Shutter Control
Where compatible control equipment is used, the tubular motor can also be integrated with a suitable smart rolling shutter controller.
The controller must support the voltage, current and directional wiring requirements of the motor.
92mm 170Nm vs 230Nm Tubular Motor
Both models use a 92mm tubular motor design, but the 230Nm model provides higher torque than the 170Nm version.
The 170Nm model is rated at 830W and 16rpm, while this 230Nm model is rated at 870W and 12rpm. The correct motor should be selected according to the required shutter torque and roller tube configuration.
92mm 230Nm Tubular Motor Applications
- Heavy-duty automatic rolling shutters
- Commercial rolling shutters
- Industrial roller shutters
- Shop rolling shutters
- Garage rolling shutters
- Workshop shutters
- Warehouse shutters
- Showroom shutters
- Storage facility shutters
- High-torque tubular motor applications
- Replacement tubular motors
Professional Tubular Motor Installation
Professional installation is recommended to ensure correct motor sizing, roller tube compatibility, adapter selection, electrical wiring and limit adjustment.
Before selecting the 92mm 230Nm motor, the actual rolling shutter weight and roller tube dimensions should be checked to confirm compatibility.
Rolling Shutter Tubular Motor 92mm 230Nm Supplier in UAE
AAM Automatic Doors & Gate Barriers supplies 92mm 230Nm tubular motors in UAE for compatible commercial and heavy-duty automatic rolling shutter applications.
Supply and installation services are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
