Rolling Shutter Remote Receiver Controller UAE
Price 499 AEDIn Stock
The Rolling Shutter Remote Receiver Controller is a wireless control solution designed for compatible automatic rolling shutter and roller door motors. It allows the shutter motor to be operated conveniently using both manual controls and wireless remote controls.
Operating on 220V AC, the controller is designed for compatible AC single-phase rolling shutter motors and provides a contact rating of up to 220V / 10A. It supports 433.92MHz wireless remote control for convenient opening, stopping and closing of automatic shutters.
The compact receiver control box is suitable for shops, garages, warehouses, offices, workshops and other residential or commercial rolling shutter applications.
Key Features
- Rolling shutter remote receiver controller
- Model FBD-JLM-888
- 220V AC working voltage
- 433.92MHz wireless remote control
- 220V / 10A contact rating
- Manual and wireless remote operation
- Designed for compatible AC single-phase motors
- OPEN / STOP / CLOSE shutter control
- Compact receiver control box
- Suitable for rolling shutter doors
- Suitable for roller doors
- Suitable for shutter window motors
- Suitable for residential and commercial applications
- Easy replacement for compatible shutter controllers
Technical Specifications
| Product Type | Rolling Shutter Remote Receiver Controller |
| Model | FBD-JLM-888 |
| Working Voltage | 220V AC |
| Wireless Frequency | 433.92MHz |
| Contact Rating | 220V / 10A |
| Controller Size | 102 × 80 × 35mm |
| Controller Weight | 217g |
| Operating Temperature | -10°C to +70°C |
| Motor Compatibility | Compatible AC Single-Phase Rolling Shutter Motors |
| Control Method | Manual + Wireless Remote Control |
| Application | Automatic Rolling Shutter / Roller Door Control |
220V Rolling Shutter Controller
The controller operates from a 220V AC electrical supply and is designed to control compatible single-phase rolling shutter motors.
It provides a convenient control interface between the shutter motor, manual control input and wireless remote-control system.
433.92MHz Rolling Shutter Receiver
The integrated wireless receiver supports 433.92MHz remote-control operation, allowing compatible transmitters to operate the automatic rolling shutter.
This provides convenient wireless control without requiring the user to operate the shutter directly from a wall-mounted switch.
Open Stop Close Rolling Shutter Control
The rolling shutter controller provides convenient OPEN / STOP / CLOSE operation for compatible automatic shutter motors.
Users can open the shutter, stop movement when required and close the shutter using the appropriate control buttons.
Rolling Shutter Remote Control Receiver
The controller combines the motor control function with a wireless receiver, providing a practical solution for adding remote-control operation to compatible rolling shutter systems.
Compatible remote transmitters can be programmed to the receiver for convenient everyday shutter operation.
Manual & Remote Shutter Control
The controller supports both manual and wireless remote operation.
This allows the rolling shutter to be operated from a compatible local control switch as well as from programmed wireless remote controls.
Controller for Single-Phase Shutter Motors
The controller is designed for compatible AC single-phase rolling shutter motors.
Before installation, the motor voltage, current and wiring configuration should be checked to confirm compatibility with the controller.
Rolling Shutter Motor Receiver Replacement
The FBD-JLM-888 can be used as a replacement controller where the existing rolling shutter motor and electrical configuration are compatible.
Before replacing another controller, check the supply voltage, motor type, motor current, directional wiring and remote-control frequency.
Rolling Shutter Controller for Shops
The wireless shutter controller is suitable for compatible automatic rolling shutters installed at retail shops, supermarkets, showrooms and other commercial entrances.
Remote operation provides convenient opening and closing of the shutter at the beginning and end of business hours.
Rolling Shutter Controller for Garages
The controller can also be used with compatible garage rolling shutter motors, providing convenient wireless opening and closing using a remote transmitter.
Rolling Shutter Controller for Warehouses
Compatible warehouse roller shutters can use the controller where the installed single-phase motor falls within the electrical rating of the control unit.
Rolling Shutter Controller Applications
- Automatic rolling shutter doors
- Roller shutter motors
- Shop rolling shutters
- Garage roller shutters
- Warehouse shutters
- Workshop shutters
- Commercial roller doors
- Automatic shutter windows
- Remote-control shutter systems
- Replacement shutter receivers
Rolling Shutter Controller Installation
Professional installation is recommended to ensure correct power supply, motor wiring, opening and closing direction, remote programming and safe electrical connections.
Before installation, confirm that the rolling shutter motor is compatible with the controller's voltage and contact rating.
Rolling Shutter Remote Receiver Controller Supplier in UAE
AAM Automatic Doors & Gate Barriers supplies rolling shutter remote receiver controllers in UAE for compatible automatic roller shutter and shutter motor systems.
Supply and installation services are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
