FAAC 415

FAAC 415 Swing Gate Motor in UAE

• FAAC 415 230V
• 230V Electromechanical operator
• Max width single leaf 2,5 – 4 m (with electric lock)
• Use frequency 30%
• Off axis” thrust operator.
• Opening and closing mechanical stops included.
• Horizontal exit for cables to allow near to ground installation (low installation).

Technical Specifications:

• Power supply voltage : 220-240V~ 50/60 Hz
• Electric motor : Asynchronous single phase
• Max. power : 300 W
• Max expressed force : 3000 N (*)
• Rod max speed : 16 mm/s (*)
• Rod travel : 300 mm (350 mm without mechanical stops)
• Max. leaf opening angle : 110°
• Operating ambient temperature : -20°C ÷ + 55°C
• Thermal protection : 140°C
• Protection class : IP54
• Weight : 7.8 Kg
• Use frequency : S3 – 30%
• Max. leaf width : 2,5 m (3 m with electric lock)
• Mounting brackets : Rear attachment to be welded/screwed
• Dimensions (LxDxH) : 836 x 101 x 147 mm
