CAME G6000 Parking Gate Barrier UAE

The CAME G6000 Parking Gate Barrier is a professional automatic boom barrier designed for controlling vehicle entrances with a maximum net clearance of up to 6.5 metres. Part of the CAME GARD series, the G6000 is suitable for residential, commercial and industrial parking and access-control applications.

The CAME 001G6000 operates from a 230V AC mains supply and uses a 24V DC gearmotor designed for heavy-duty service. With 300W power, 600Nm torque and an opening time of approximately 4 to 8 seconds, it provides dependable vehicle access control for busy entrances.

The G6000 features a galvanized and painted steel cabinet designed to accommodate compatible CAME accessories. The built-in control system allows remote controls, photocell sensors, loop detectors, access-control equipment and other command and safety devices to be integrated according to the installation requirements.

With an IP54 protection rating and operating temperature from -20°C to +55°C, the CAME G6000 provides a reliable automatic barrier solution for apartment buildings, commercial parking areas, factories, warehouses and other high-traffic vehicle entrances.

Key Features

• Original CAME automatic parking gate barrier
• CAME GARD Series
• Model G6000
• Product code 001G6000
• Maximum net clearance up to 6.5 metres
• 230V AC mains power supply
• 24V DC gearmotor
• 300W motor power
• 600Nm torque
• 4–8 second opening time at 90°
• Designed for heavy-duty service
• Built-in electronic control panel
• Galvanized and painted steel cabinet
• Compatible with photocell safety sensors
• Compatible with vehicle loop detectors
• Compatible with remote controls and receivers
• Suitable for access-control integration
• Emergency battery operation available with compatible accessory
• IP54 protection rating
• Suitable for high-traffic vehicle entrances

Technical Specifications

CAME 001G6000 24V Automatic Boom Barrier for Entrances up to 6.5 Metres

The CAME G6000 is designed for automatic vehicle entrances requiring a long barrier boom. With a maximum net passage clearance of 6.5 metres, it is suitable for wide parking entrances, commercial properties, residential compounds and industrial facilities.

24V DC Heavy-Duty Gearmotor

The CAME G6000 uses a 24V DC gearmotor designed for heavy-duty service. The low-voltage motor provides dependable opening and closing performance for locations with frequent vehicle movement.

The barrier receives a 230V AC mains supply, while the internal gearmotor operates at 24V DC.

300W Motor with 600Nm Torque

The G6000 is equipped with a 300W motor delivering 600Nm of torque. The powerful drive system is designed to operate the longer boom configuration required for entrances up to 6.5 metres wide.

4–8 Second Opening Time

The CAME G6000 provides a maneuvering time of approximately 4 to 8 seconds at 90°, providing controlled boom movement for wide vehicle entrances.

Designed for Heavy-Duty Service

The CAME G6000 is designed for heavy-duty service, making it suitable for vehicle entrances requiring frequent automatic barrier operation.

Typical installations include apartment buildings, commercial parking facilities, industrial plants, warehouses, residential compounds and controlled vehicle entrances.

Built-In Electronic Control Panel

The CAME G6000 incorporates an electronic control panel inside the barrier cabinet for management of opening, closing and connected command and safety accessories.

Photocell Safety Sensor Compatible

Compatible CAME photocell sensors can be integrated with the G6000 to detect vehicles or obstacles within the controlled entrance.

Correct installation and programming of safety devices helps prevent the boom from closing while a vehicle or obstacle is within the protected area.

Vehicle Loop Detector Integration

The CAME G6000 can be integrated with a compatible vehicle loop detector. An induction loop installed in the road can detect vehicles and provide a signal to the automatic barrier control system.

Loop detector systems are particularly suitable for parking entrances, exits, factories, warehouses and commercial vehicle access points.

Remote Control Operation

Compatible CAME radio receivers and remote controls can be used with the G6000, allowing authorized users, guards or security personnel to operate the parking barrier remotely.

Access Control Integration

The CAME G6000 can be integrated into a complete vehicle access-control system using compatible card readers, UHF long-range RFID readers, push buttons, intercom systems and other authorized-entry devices.

Emergency Battery Operation

The G6000 supports a compatible emergency operation and battery-charging circuit board, allowing backup batteries to be incorporated into appropriately configured installations.

Galvanized & Painted Steel Cabinet

The CAME G6000 cabinet is manufactured from galvanized and painted steel and is designed to accommodate compatible barrier accessories and control equipment.

IP54 Protection

The CAME G6000 has an IP54 protection rating and an operating temperature range from -20°C to +55°C, making it suitable for professional outdoor vehicle access installations.

Applications

• Residential parking entrances
• Apartment buildings
• Residential compounds
• Commercial parking areas
• Office buildings
• Shopping centres
• Hotels and hospitals
• Factories and warehouses
• Industrial facilities
• Logistics centres
• Security checkpoints
• Vehicle access-control entrances

CAME G6000 Parking Gate Barrier Supplier in UAE

AAM Automatic Doors & Gate Barriers supplies CAME G6000 parking gate barriers in UAE together with compatible boom arms, remote controls, photocell sensors, loop detectors, push buttons, access-control equipment and gate barrier spare parts.

Supply, installation, programming, repair and technical support are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
